Internal 3.5"
drive slot
007-4263-001
Internal 3.5"
drive bay
(hard disk drive installed)
5.25-inch and 3.5-inch Drive Bays
Figure 1-5
Internal Structure
5.25" drive bay
(CD-ROM drive installed)
5.25" drive bay
5.25" drive bay
3.5" drive bay
3.5" drive bay
(floppy disk drive
installed)
