• Rear Panel
As shown in Figure 1-2, the rear panel includes the AC power input socket, the rear
system fans, six expansion slots, and the I/O panel. Figure 1-3 shows a detailed
view of the I/O panel.
AC power
input socket
Voltage select
switch
Power supply
fan
System label
1
2
2
I/O panel
1
System
board screw
Video-Out
ports
Expansion
slots
Figure 1-2 Rear Panel
Power supply
rear screws
Locking loop
Locking loop slot
Side panel
retaining screw
Rear fan
Side panel
retaining screw
Kensington
lock slot
External Structure
3
