INVT Goodrive300-01A Series Operation Manual page 35

Goodrive300-01A series VFD for air compressor
Function
Name
code
of the iron core of
asynchronous motor 1
Saturation coefficient 3
P02.13 of the iron core of
asynchronous motor 1
Saturation coefficient 4
P02.14 of the iron core of
asynchronous motor 1
Rated power of
P02.15
synchronous motor 1
Rated frequency of
P02.16
synchronous motor 1
Pole pairs of
P02.17
synchronous motor 1
Rated voltage of
P02.18
synchronous motor 1
Rated current of
P02.19
synchronous motor 1
Stator resistor of
P02.20
synchronous motor 1
Direct-axis inductance
P02.21
of synchronous motor 1
Quadrature-axis
P02.22 inductance of
synchronous motor 1
Counter-emf constant
P02.23
of synchronous motor 1
Overload protection
P02.26
selection of motor 1
Overload protection
P02.27
coefficient of motor 1
Parameter description
0.0–100.0%
0.0–100.0%
0.1–3000.0kW
0.01Hz–P00.03 (max. frequency)
1–50
0–1200V
0.8–6000.0A
0.001–65.535Ω
0.01–655.35mH
0.01–655.35mH
0–10000
0: No protection
1: Normal motor (with low speed
compensation)
2: Frequency-conversion motor (without low
speed compensation)
Motor overload multiple M = Iout/(In*K)
In is rated motor current, Iout is VFD output
current, K is motor overload protection
coefficient.
The smaller the K is, the larger the value of M
is; the smaller the value of M is, the easier the
protection is.
-31-
Function code description
Default
Modify
value
◎
57.0%
◎
40.0%
Depend
◎
on model
◎
50.00Hz
◎
2
Depend
◎
on model
Depend
◎
on model
Depend
○
on model
Depend
○
on model
Depend
○
on model
○
350
◎
2
○
100.0%
