INVT Goodrive300-01A Series Operation Manual page 38

Goodrive300-01A series VFD for air compressor
Function
Name
code
V/F frequency point 1
P04.03
of motor 1
V/F voltage point 1 of
P04.04
motor 1
V/F frequency point 2
P04.05
of motor 1
V/F voltage point 2 of
P04.06
motor 1
V/F frequency point 3
P04.07
of motor 1
V/F voltage point 3 of
P04.08
motor 1
V/F slip compensation
P04.09
gain of motor 1
Low-frequency
P04.10 vibration control factor
of motor 1
High-frequency
P04.11 vibration control factor
of motor 1
Vibration control
P04.12
threshold of motor 1
Energy conservation
P04.26
running selection
Flux-weakening
P04.33 coefficient in constant
power area
P05.00 Reserved
S1 terminal function
P05.01
selection
S2 terminal function
P05.02
selection
S3 terminal function
P05.03
selection
S4 terminal function
P05.04
selection
S5 terminal function
P05.05
selection
P05.06 Reserved
Parameter description
0.00Hz–P04.05
0.0%–110.0% (rated voltage of motor 1)
P04.03– P04.07
0.0%–110.0% (rated voltage of motor 1)
P04.05–P02.02 (rated frequency of motor 1)
/P04.05–P02.16 (rated frequency of motor 1)
0.0%–110.0% (rated voltage of motor 1)
0.0–200.0%
0–100
0–100
0.00Hz–P00.03 (max. frequency)
0: No action
1: Automatic energy-saving running
1.00–1.30
Reserved
0: No function
1: Forward running
2: Reverse running
3: Three-line running control
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Running pause
9: External fault input
10–24: Reserved
-34-
Function code description
Default
Modify
value
○
0.00Hz
○
00.0%
○
00.00Hz
○
00.0%
○
00.00Hz
○
00.0%
○
100.0%
○
10
○
10
○
30.00Hz
◎
0
○
1.00
◎
0
◎
0
◎
0
◎
0
◎
0
◎
0
◎
