Goodrive300-01A series VFD for air compressor
Function
Name
code
P19.07 Running time of part 3
P19.08 Running time of part 4
P19.09 Running time of part 5
Actual output power of
P19.10
the motor
P19.11 Present pressure
P19.12 Present temperature
P19.13 Signal state 1
Parameter description
Display motor output power, it can be
calibrated by P18.22.
Range: 0.0–6553.5kw
Display the discharge pressure value
detected currently.
Current
pressure Mpa
P18.37=0
P18.04
P19.11
0
P05.32
Current
pressure
P18.37=1
Mpa
P18.38
P19.11
0
P05.42
Range: 0.00–655.35Mpa
Display the machine head temperature
detected currently.
Current temperature
P18.03=0
150
P19.12
P18.28
0
-20
Current temperature
P18.03=1
150
P19.12
P18.32
0
-20
Range: -20–150° C
0000–0xFFFF
BIT0: Air filter blockage signal
1: Fault; 0: Normal
-55-
Function code description
P1 input
P17.19 P05.34
voltage
P17.21 P05.44
P2 input
voltage
P18.29
P17.20
PT1 input
voltage
P18.33
P17.22
PT2 input
voltage
Default
Modify
value
●
0
●
0
●
0
●
0.0kw
●
0.00Mpa
●
0° C
●
0
