INVT Goodrive300-01A Series Operation Manual page 42

Goodrive300-01A series VFD for air compressor
Function
Name
code
Lower limit of AO1
P06.17
output
Corresponding AO1
P06.18
output of lower limit
Upper limit of AO1
P06.19
output
Corresponding AO1
P06.20
output of upper limit
P06.21 AO1 output filter time 0.000s–10.000s
P07.00 User password
Function parameter
P07.01
current of the motor)
6: Output voltage
7: Output power
8: Reserved
9: Output torque
10–13: Reserved
14: Value 1 set through Modbus
communication
15: Value 2 set through Modbus
communication
16–21: Reserved
22: Torque current (relative to three times the
rated current of the motor)
23: Ramp frequency reference (with sign)
24: Temperature PID output
25–30: Reserved
-100.0%–P06.19
0.00V–10.00V
P06.17–100.0%
0.00V–10.00V
0–65535
0: No operation
1: Uploading function parameters from the
machine to keypad
2: Downloading function parameters
(including the motor parameters) from the
keypad to machine
3: Downloading function parameters
copy (excluding motor parameters of the P02 and
P12 groups) from the keypad to machine
4: Downloading function parameters (only
motor parameters of the P02 and P12 groups)
from the keypad to machine
Note:
After the parameter is set to 1, 2, 3 or 4, and
Parameter description
-38-
Function code description
Default
Modify
value
○
0.0%
○
0.00V
○
100.0%
○
10.00V
○
0.000s
○
0
◎
0
