Goodrive300-01A series VFD for air compressor
Function
Name
code
Local communication
P14.00
address
Communication baud
P14.01
rated setup
P14.02 Data bit check setup
Communication
P14.03
response delay
Communication
P14.04
timeout fault time
Transmission error
P14.05
processing
Communication
P14.06 processing action
selection
P17.00 Setting frequency
P17.01 Output frequency
Ramps reference
P17.02
frequency
P17.03 Output voltage
P17.04 Output current
P17.05 Motor speed
Parameter description
1–247, 0 is broadcast address
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
0: No parity check (N, 8, 1) for RTU
1: Even parity (E, 8, 1) for RTU
2: Odd parity (O, 8, 1) for RTU
3: No parity check (N, 8, 2) for RTU
4: Even parity (E, 8, 2) for RTU
5: Odd parity (O, 8, 2) for RTU
0–200ms
0.0 (invalid), 0.1–60.0s
0: Alarm and coast to stop
1: Do not alarm and continue running
2: Do not alarm and stop as per stop mode
(under communication control mode only)
3: Do not alarm and stop as per stop mode
(under all control modes)
0x00–0x11
LED ones: write operation action
0: There is response for write operation
1: There is no response for write operation
LED tens: Communication encryption
processing
0: Communication encryption setting is invalid
1: Communication encryption setting is valid
0.00Hz–P00.03
0.00Hz–P00.03
0.00Hz–P00.03
0–1200V
0.0–3000.0A
0–65535RPM
-46-
Function code description
Default
Modify
value
○
2
○
4
○
1
○
5ms
○
0.0s
○
0
○
0x00
●
0.00Hz
●
0.00Hz
●
0.00Hz
●
0V
●
0.0A
●
0 RPM
