Appendix A Product Dimension; Keypad Diagram; External Keypad Installation Dimensions - INVT Goodrive300-01A Series Operation Manual

Goodrive300-01A series VFD for air compressor
A.1 Keypad diagram
Digital display area
Increase/decrease key
Program/exit key
Short-cut multi-function key
A.2 External keypad installation dimensions
Simple keypad bracket
（ 61006-00911)

Appendix A Product dimension

Run key
88.0
57.1
54.3
82.0
Customer installation
dimensions
-73-
Appendix A
Function indicator
Unit indicator
Digital potentiometer
Confirmation key
Right shift key
Stop/fault reset key
