INVT Goodrive300-01A Series Operation Manual page 51

Goodrive300-01A series VFD for air compressor
Function
Name
code
P17.06 Torque current
P17.07 Excitation current
P17.08 Motor power
P17.09 Output torque
Estimated motor
P17.10
frequency
P17.11 DC bus voltage
Digital input terminal
P17.12
state
Digital output terminal
P17.13
state
P17.16 Master fault code
P17.17 Reserved
P17.19 P1-input voltage
P17.20 PT1 input voltage
P17.21 P2- input voltage
Parameter description
-3000.0–3000.0A
-3000.0–3000.0A
-300.0%–300.0% (relative to rated motor
power)
-250.0–250.0%
0.00– P00.03
0.0–2000.0V
0000–00FF
0000–000F
0–43 (see P07.27–P07.32 for details)
0–38
Display analog input voltage value of P1-
channel, 2.00V-10.00V corresponds to
4-20mA; P05.32-P05.34 corresponds to
pressure 0.0-P18.04. If P1- input voltage is
larger than 9.8V or less than 1V, it indicates
pressure signal fault occurs.
Range: 0.00–10.00V
Display analog input voltage value of PT1
channel. Under air-compressor mode,
connect to PT100 thermal resistor
temperature sensor, different temperature
generates different resistor value, and
different resistor value corresponds to
different input voltages, therefore, the input
voltage value can correspond to
corresponding detection temperature. Input
voltage P18.28-P18.29 corresponds to -20° C
to +150° C.
Setting range: 0.00–10.00V
Display analog input voltage value of P2-
channel, 2.00V-10.00V corresponds to
4-20mA; P05.42-P05.44 corresponds to
pressure 0.0- P18.38. When the input voltage
of P2- is larger than 9.8V or less than 1V, it
indicates pressure signal fault occurs.
-47-
Function code description
Default
Modify
value
●
0.0A
●
0.0A
●
0.0%
●
0.0%
●
0.00Hz
●
0V
●
0
●
0
●
0
●
0
●
0.00V
●
0.00V
●
0.00V
