INVT Goodrive300-01A Series Operation Manual page 52

Goodrive300-01A series VFD for air compressor
Function
Name
code
P17.22 PT2 input voltage
P17.23 PID reference value
P17.24 PID feedback value
P17.25 Motor power factor
P17.26 Current running time 0–65535m
P17.28 ASR controller output -300.0%–300.0% (rated motor current)
Magnetic pole angle of
P17.29
synchronous motor
Phase compensation
P17.30 quantity of
synchronous motor
P17.36 Output torque
P17.38 PID output value
Air compressor control
P18.00
mode
P18.01 Sleep function
Parameter description
Setting range: 0.00–10.00V
Display analog input voltage value of PT2
channel. Under air-compressor mode,
connect to PT100 thermal resistor
temperature sensor, different temperature
generates corresponding resistor value, and
different resistor value corresponds to
corresponding input voltage, therefore, input
voltage value can correspond to
corresponding detection temperature. Input
voltage P18.32- P18.33 correspond to
-20° Cto +150° C.
Setting range: 0.00–10.00V
Display the set value of discharge pressure
signal. 100% corresponds to the upper limit
value of discharge pressure sensor (P18.04)
(if P18.37=1, 100% corresponds to P18.38).
Setting range: -100.0–100.0%
Display the detection value of discharge
pressure signal.
Setting range: -100.0–100.0%
-1.00–1.00
0.0–360.0
-180.0–180.0
-3000.0Nm–3000.0Nm
Display the output value of PID control of
discharge pressure signal; 100% corresponds
to max. output frequency P00.03.
Setting range: -100.00–100.00%
0: Invalid;
1: Air-compressor control mode
Note: When P18.00=1, P19 air-compressor
state checking group is valid.
0: Invalid
-48-
Function code description
Default
Modify
value
●
0.00V
●
0.0%
●
0.0%
●
0.0
●
0m
●
0.0%
●
0.0
●
0.0
●
0.0Nm
●
0.00%
◎
0
◎
1
