Reactor - INVT Goodrive300-01A Series Operation Manual

Goodrive300-01A series VFD for air compressor
VFD model
GD300-01A-055G-4
GD300-01A-075G-4
GD300-01A-090G-4
GD300-01A-110G-4
GD300-01A-132G-4
GD300-01A-160G-4
GD300-01A-185G-4
GD300-01A-200G-4
B.3 Reactor
Reactor model selections for GD300-01A are shown below.
VFD power
GD300-01A-132G-4
GD300-01A-160G-4
GD300-01A-185G-4
GD300-01A-200G-4
Input filter
FLT-P04150L-B
FLT-P04240L-B
FLT-P04400L-B
Input reactor
ACL2-160-4
ACL2-160-4
ACL2-200-4
ACL2-200-4
-81-
Output filter
FLT-L04150L-B
FLT-L04240L-B
FLT-L04400L-B
DC reactor Output reactor
DCL2-132-4
DCL2-160-4
DCL2-220-4
DCL2-220-4
Appendix B
OCL2-160-4
OCL2-200-4
OCL2-200-4
OCL2-200-4
