3 – GENERAL SPECIFICATIONS

3.1. PRINTING SPECIFICATIONS

Printing method
Dot density
Printing direction
Printing width
Printing speed
Paper feed speed
(1) 'dpi': dots per inch. 1 inch = 25.4mm; 203 dpi = 8 dots per mm
(2) Printing speed could vary depending on the print head temperature as well as the command processing and
the data transmission speed. Low transmission speed could cause intermittent printing. It is recommended to
transmit data to the printer as quickly as possible.

3.2. CHARACTER SPECIFICATIONS

Character per line (default)
Character spacing (default)
Character structure
Character size (mm)
Number of characters
Line spacing (default)
(1) Characters can be scaled up to 64 times bigger than their normal size.
'cpl': characters per line.
(2)

3.3. PAPER SPECIFICATIONS

Paper type
Paper loading
Width
Roll size
Paper specifications
Thermal line printing
203 x 203 dpi
Unidirectional with friction feed
CAPD247 54mm (432 dots)
CAPD347 72mm (576 dots)
High speed mode: up to 200mm/s
200mm/s (continuous paper feed)
Font A: 27
Font B: 36
0.5 mm (4 dots)
Font A: 12 x 24 dots (1.5 x 3 mm). (default)
Font B: 8 x 16 dots (1 x 2 mm).
Standard
(1)
Double-width
Double-height
Double width/height:
Alphanumeric characters:
Extended Graphics:
1,875mm (15 dots)
Thermal
Automatic.
58mm (+0/-1) → CAPD247 printing mechanism
80mm (+0/-1) → CAPD347 printing mechanism
Inner diameter: 25m minimum
Papers I
Nippon Paper
Oji Paper
Mitsubishi Paper mills limited
Papierfabrik August Koehler
TS2000 PRINTERS OPERATION MANUAL
(1)
(CAPD247)
(CAPD247)
Font A WxH(mm) – cpl
1.5 x 3 – 24
3 x 3 – 12
1.5 x 6 – 24
3 x 6 – 12
95
128 per page
TF50KS-E2D
TP50KJ-R
PD160R-63
PD160R-N
P220VBB-1
AG KT55F20
(2)
(2) Font B WxH(mm) – cpl
1 x 2 – 32
2 x 2 – 16
1 x 4 – 32
2 x 4 – 16
(NOTES 1-2)
