TS2000 PRINTERS OPERATION MANUAL
PAPER OUTPUT BY CHUTE
.
In this system, the developer should only design the chute for the ticket pick up.
Fenix provides an additional piece which is installed on the TS2000 and allowing assembly the platen
block in the print mechanism (See APPENDIX – HOW TO ORDER).
Here are some images as an example:
Platen block optional support
Chute for ticket picked up
Fig.4.5. TS2000 in paper output by chute example.
