[Notes]
This command is effective for all characters, except for HRI characters.
When characters are enlarged with different sizes on one line, all the characters on
the line are aligned at the baseline.
The ESC ! command can also turn double-width and double-height modes on or off.
However, the setting of the last received command is effective.
[Default]
n = <00>H
[Reference]
ESC !
GS ( A pL pH n m
[Name]
Execute test print
[Format]
ASCII
Hex
Decimal
[Range]
(pL + (pH x 256)) = 2
<00>H ≤ n ≤ <02>H, <30>H ≤ n ≤ <32>H
<01>H ≤ n ≤ <03>H, <31>H ≤ m ≤ <33>H
[Description]
Executes a test print with a specified test pattern on a specified paper.
pL, ph specifies (pL+(phx256)) for the number of the bytes after ph (n and m).
n specifies the paper to be tested.
<00> / <30>H
<01> / <31>H
<02> / <32>H
• m specifies a test pattern.
<01> / <31>H
<02> / <32>H
<03> / <33>H
[Notes]
This command has enabled only when processed at the beginning of a line.
After the test print is finished, the printer resets itself automatically. Therefore, data
already defined before this command is executed, such as user-defined buffer and
print buffer are cleared; and each setting returns to the default value.
The printer cuts the paper at the end of the test print.
G S ( C pL pH NULL 6 NULL C L R
[Name]
Erase all logos
[Format]
ASCII
Hex
Decimal
[Range]
pL = <06>H (fixed), pH = <00>H (fixed)
[Description]
Erases all logos stored in non-volatile memory.
[Reference]
FS p, FS q commands.
GS ( G n L n H m L m H
[Name]
Set ticket length and cut offset related to black mark
[Format]
ASCII
Hex
0 ≤ (nL + nH x 256) ≤ 65535
[Range]
0 ≤ (mL + mH x 256) ≤ 65535
(where <00>H ≤ nL, nH, mL and mH ≤ <FF>H)
[Description]
(nL + nH x 256) specifies the total ticket length in dots (0.125 mm) and (mL + mH x
256) sets the offset distance, also in dots, between the top of the black mark and the
next cutting line of the ticket in the paper feed direction (see section - Black mark
sensor).
GS
(
1D
28
29
40
(where pL = <02>H, pH = <00>H)
n
Paper
Paper roll
m
Test pattern
Hexadecimal dump
Printer status print
Rolling pattern print
GS
(
C
1D
28
43
29
40
67
GS
(
G
1D
28
47
TS2000 PRINTERS OPERATION MANUAL
A
pL
pH
41
pL
pH
65
pL
pH
pL
pH
NULL
pL
pH
00
pL
pH
00
nL
nH
mL
mH
nL
nH
mL
mH
n
m
n
m
n
m
6
NULL C
L
36
00
43
4C
54
00
67
76
R
52
82
40/58
