Fenix TS2000 Series Operation Manual page 36

ESC a n
[Name] Select justification
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <02>H, <30>H ≤ n ≤ <32>H
[Range]
[Description] Aligns all the data in one line to the specified position.
n selects the justification as follows:
<00>H / <30>H
<01>H / <31>H
<02>H / <32>H
[Notes] The command is enabled only when processed at the beginning of the line.
●
This command executes justification in the printing area.
●
[Reference] ESC !
[Example]
Left justification
ABC
ABCD
ABCDE
ESC c 4 n
[Name] Select paper-near-end sensor to stop printing
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <FF>H
[Range]
[Description] Selects whether the paper-near-end sensor stops printing.
When the bit 1 of n is 0, paper near-end sensor does not stop printing.
When the bit 1 of n is 1, paper near-end sensor will stop printing.
[Notes] When bit 1 is on, in paper-near-end is detected, the printer goes offline and stop
printing.
ESC c 5 n
[Name] Enable/disable the on-board button
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <FF>H
[Range]
[Description] Enables or disables the on-board button.
When the LSB of n is 0, the on-board button is disabled.
When the LSB of n is 1, the on-board button is enabled.
[Notes] Only the lowest bit of n is valid.
[Default] n = <00>H
ESC d n
[Name] Print and feed n lines
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <FF>H
[Range]
[Description] Prints the data in the print buffer and feeds n character lines.
ESC a
1B 61
27 97
n Justification
Left justification
Centered
Right justification
ESC c 4
1B 63 34
27 99 52
ESC c 5
1B 63 35
27 99 53
ESC d
1B 64
27 100
TS2000 PRINTERS OPERATION MANUAL
n
n
n
Centered
ABC
ABCD
ABCDE
n
n
n
n
n
n
n
n
n
Right justification
ABC
ABCD
ABCDE
36/58
