Fenix TS2000 Series Operation Manual page 37

[Notes] This command sets the print starting position to the beginning of the line.
●
This command does not affect the line spacing set by ESC 2 or ESC 3.
●
The maximum paper feed amount is 1016 mm {40"}. If the paper feed amount (n x
●
line spacing) of more than 1016 mm {40"} is specified, the printer feeds the paper
only 1016 mm {40"}.
Every line feed corresponds to the current selected font height (24 dots for Font A
●
and 16 dots for Font B).
[Reference] ESC 2, ESC 3.
ESC i
[Name] Full Cut
[Format] ASCII
Hex
Decimal
[Description] Cuts the paper completely in the current position.
[Notes] If this command is sent without cutter connection the printer enters cutter error status.
●
The interval between each cutting operation must be two seconds or more.
●
When the black mark sensor is set to be effective, the printer feeds paper to (black
●
mark ± [(value which is set by GS ( F) x 0.125mm]) and cuts it. After cutting, it feeds
paper to the position specified by the command GS ( F. See section – Black mark
sensor.
[Reference] GS ( F, ESC m, GS V
ESC j n
[Name] Back feed paper
[Format] ASCII
Hex
Decimal
[Range]
[Description] Back feeds the paper [n x 0.0625 mm (0.0024")].
[Notes] This command is only effective when the optical mark sensor is enabled.
●
Allows readjust the paper position when the black mark has surpassed the black
●
mark sensor, and it is needed back feed paper to prepare the cutting.
ESC m
[Name] Partial Cut
[Format] ASCII
Hex
Decimal
[Description] Cuts the paper partially in the current position.
[Notes] If this command is sent without cutter connection the printer enters cutter error
●
status.
The interval between each cutting operation must be two seconds or more.
●
This command performs the partial cut even when the black mark is enabled, but no
●
action relative to black mark is performed.
[Reference] ESC i, GS V.
ESC t n
[Name] Selects the character tables
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <03>H, <30>H ≤ n ≤ <33>H
[Range]
[Description] Selects the character tables between the internal ones or the external ones loaded.
ESC i
1B 69
27 105
ESC j n
1B 6A n
27 106 n
<00>H ≤ n ≤ <FF>H
ESC m
1B 6d
27 109
ESC t n
1B 74 n
27 116 n
TS2000 PRINTERS OPERATION MANUAL
37/58
