GS w n
[Name] Set bar code width
[Format] ASCII
Hex
Decimal
<02>H ≤ n ≤ <06>H
[Range]
[Description] Sets the horizontal size of the bar code.
n specifies the bar code width as follows:
n
<02>H
<03>H
<04>H
<05>H
<06>H
Multi-level bar codes are JAN 13(EAN13), CODE 128.
Binary-level bar codes are ITF, CODE39.
[Default] n = <03>H
[Reference] GS k
FS p n m
[Name] Print NV bit image
[Format] ASCII
Hex
Decimal
<01>H ≤ n ≤ number of saved logo;
[Range]
[Description] Prints a NV bit image n using the mode specified by m.
m
<30>H
<31>H
<32>H
<33>H
[dpi: dots per 25.4 mm]
n is the number of the NV bit image (always 1).
m specifies the bit image mode.
[Notes] NV bit image means a bit image which is defined in a non-volatile memory by FS q
●
and printed by FS p.
This command is not effective when the specified NV bit image has not been defined.
●
This command is effective only when there is no data in the print buffer.
●
This command is not affected by print modes (emphasized, double-strike, underline,
●
character size, white/black reverse printing, etc.).
If the printing area width set by GS L for the NV bit image is less than one vertical
●
line, the following processing is performed only on the line in question. However, in
NV bit image mode, one vertical line means 1 dot in normal mode (m=30H) and in
double-height mode (m=31H), and it means 2 dots in double-width mode (m=32H)
and in quadruple mode (m=33H).
If the printing area width cannot be extended by one line vertically, the left margin is
●
reduced to accommodate one line vertically.
The printing area width is extended to the right in NV bit image mode up to one line
●
vertically. In this case, printing does not exceed the printable area.
GS w
1D 77
29 119
Module Width (mm) for
Multi-level Bar Code
0.282
0.423
0.564
0.706
0.847
FS p
1C 70
28 112
Mode
Dot Density
Normal 203.2 dpi
Double-width 203.2 dpi
Double-height 101.6 dpi
Quadruple 101.6 dpi
TS2000 PRINTERS OPERATION MANUAL
n
n
n
Binary-level Bar Code
Thin element
width (mm)
0.282
0.426
0.564
0.706
0.847
n m
n m
n m
<30>H ≤ m ≤ <33>H
Vertical Horizontal
Dot Density
203.2 dpi
101.6 dpi
203.2 dpi
101.6 dpi
Thick element
width (mm)
0.706
1.129
1.411
1.834
2.258
