4.5. USB INTERFACE

The TS2000 USB interface has the following general features:
•
•
•
•
4.5.1- Assignments of USB connector terminals
Pin Signal name
1
2
3
4
5
USB Mini-B series connector has to be used.
4.6. PHOTO-SENSORS
The TS2000 optionally allows control up to 3 auxiliary sensors, for which a specific functionality
has been assigned. The sensors are not included in the TS2000 printer, but can be purchased as
an accessory ( See APPENDIX – HOW TO ORDER - ACCESSORIES ) :
USB specification
Transfer type
Maximum receive/transmit endpoint size
Current consumption from USB bus
VBUS
D –
D+
GND
NC
Fig.4.9. Photo-sensors interface pins.
Pin
number
10 Driver
11 INPUT
12 Driver
13 INTPUT Ticket picked-up signal
14 Driver
15 INTPUT Black-mark signal
16, 17, 18 -
TS2000 PRINTERS OPERATION MANUAL
Pin #1
Fig.4.8. TS2000 USB connector.
Function
Near-end-paper diode polarization pin
Near-end-paper signal
Ticket picked-up diode polarization pin
Black-mark diode polarization pin
Signal ground
USB 2.0 (480Mbits/s full speed)
Bulk
64 bytes
2mA max.
Pin #5
