[Notes] When both double-height and double-width modes are selected, quadruple-size
●
characters are printed.
When some characters in a line are double or more height, all the characters in the
●
line are aligned at the baseline.
ESC E can also select the emphasized mode. Be careful when uses both command.
●
ESC M can also select character font type. However, the setting of the last received
●
command is effective.
GS ! can also select character size. However, the setting of the last received
●
command is effective.
If this command is not received at the beginning of a line, and the character font is to
●
be changed, all previous data in the print buffer is printed and the ticket is placed at
the beginning of the next line.
[Default] n = <00>H
[Reference] ESC M, ESC E, ESC G, GS !
ESC - n
[Name] Turns on/off underline mode
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <FF>H
[Range]
[Description] Sets the underline mode. Only the least significant two bits are valid for n:
[Notes] ESC ! command can turns off the underline mode.
[Default] n = <00>H
[Reference] ESC !
ESC 2
[Name] Select default line spacing
[Format] ASCII
Hex
Decimal
[Description] Selects 3.75 mm (30 x 0.125 mm) line spacing.
[Reference] ESC 3
ESC 3 n
[Name] Set line spacing
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <FF>H
[Range]
[Description] Sets the line spacing to [n x 0.125 mm].
[Default] n = <1E>H
[Reference] ESC 2
ESC @
[Name] Initialize printer
[Format] ASCII
Hex
Decimal
[Description] Clears the data in the print buffer and resets the printer settings to the settings that were
in effect when the power was turned on.
[Notes] The data in the receiver buffer is not cleared.
●
This command does not involve a hardware reset.
●
ESC -
1B 2D
27 45
n = <00>H / <30>H : Underline mode is turned off.
n = <01>H / <31>H: Set the underline thickness to 1-dot.
n = <02>H / <32>H: Set the underline thickness to 2-dots.
ESC 2
1B 32
27 50
ESC 3
1B 33
27 51
ESC @
1B 40
27 64
TS2000 PRINTERS OPERATION MANUAL
n
n
n
n
n
n
33/58
