Fenix TS2000 Series Operation Manual page 39

When the LSB of n is 1, Inverse printing mode on.
[Notes] Each character is printed upside down (180º rotating) and the sequence of
●
characters is printed backwards as well. The character sent fist is printed al the right
margin and subsequent characters are printed from right to left. The characters lines
transmission order changes from the normal mode, because the first line is sent to
the printer must be the last to appear on the ticket, and the last line is sent must be
the first to appear on the ticket.
When inverse mode is setting, the rotated mode (90º) is disabled.
●
This command is enabled only when processed at the beginning of a line.
●
[Default] n = <00>H
GS FF
[Name] Feed marked paper to print starting position
[Format] ASCII
Hex
Decimal
[Description] Feeds paper until finding the black mark. Then moves the ticket, forward or backward,
placing it at the printing position.
[Notes] This command is only effective when the optical mark sensor is enabled.
●
This command sets the next print position to the beginning of the line.
●
The maximum amount of paper feed until find the black mark is 0,5m.
●
[Reference] GS ( G
GS ! n
[Name] Select character size
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <77>H. While n ≤ <7X>H and n ≤ <X7>H
[Range]
[Description] Selects the character height using bits 0 to 3 and selects the character width using bits
4 to 7, as follows:
GS FF
1D 0C
29 12
GS !
1D 21
29 33
Horizontal size (WIDTH)
n
(in hex)
x 1 x 2
x 1 00 10
x 2 01 11
x 3 02 12
x 4 03 13
x 5 04 14
x 6 05 15
x 7 06 16
x 8 07 17
TS2000 PRINTERS OPERATION MANUAL
n
n
n
x 3 x 4 x 5 x 6
20 30 40 50
21 31 41 51
22 32 42 52
23 33 43 53
24 34 44 54
25 35 45 55
26 36 46 56
27 37 47 57
x 7 x 8
60 70
61 71
62 72
63 73
64 74
65 75
66 76
67 77
39/58
