3 – GENERAL SPECIFICATIONS

3.1- PRINTING SPECIFICATIONS

Printing method
Dot density
Printing direction
Printing width
Printing speed
Paper feed speed
Characters per line (by default):
Space between
default):
Line spacing (by default):
(1)
'dpi': dots per inch.
(2)
Printing speed could vary depending on the print head temperature as well as the
command processing and the data transmission speed. Low printing speed could
cause intermittent printing. It is recommended to transmit data to the printer as quickly
as possible.

3.2- CHARACTER SPECIFICATIONS

1) Number of characters:
2) Character structure:
3) Character size:
Standard
Width x height cpl Width x height
A Font 1,5 x 3 mm
B Font 1 x 2 mm
The space between the characters is not included. Characters can be scaled up to 64 times bigger than their
normal size.
cpl: characters per line.

3.3- PAPER SPECIFICATIONS

1) Paper type:
2) Paper width:
3) Paper roll size:
4) Specified thermal paper: At –5ºC to 50ºC

3.4- PAPER LOADING

One of the main advantages of the EPC1200 printer series is its paper loading system. It can be
carried out by any final user without having to disassemble the printer or loading the paper in a complex
paper path.
(2)
characters (by
1 inch = 25.4mm; 203 dpi = 8 dots per mm
Alphanumeric characters:
Extended graphics:
A font: 12 x 24 dots (1.5 x 3 mm).
B font: 8 x 16 dots (1 x 2 mm).
Double height
24 1,5 x 6 mm
32 1 x 4 mm
thermal paper roll
58 +0/-1mm
up to a maximum diameter of 45 mm
At –30ºC to 70ºC
At 5ºC to 40ºC
EPC1200 SERIES OPERATION MANUAL
EPC1200
Thermal line printing
203 dpi x 203 dpi
Unidirectional with friction feed
48 mm (384 dots)
High speed mode:
up to 90mm/s
90 mm/s (continuous
paper feed)
A font: 24
B font: 32
4 dots (0.5 mm)
3.75mm
95
128 per page
Double width
cpl Width x height cpl Width x height
24 3 x 3 mm 12
32 2 x 2 mm 16
TF50KS-E2D (59μm paper)
TF77KS-E2 (95μm paper)
TL69KS-HG76 (label paper)
TL51KS-R2 (High heat-resistant paper)
TL69KS-R2 (High heat-resistant paper)
TW80KK-S (2-ply thermal paper)
From Nippon Paper Industries
EPC1250
(1)
up to 50mm/s
50 mm/s (continuous
paper feed)
(selected by default)
Double width / Double height
cpl
3 x 6 mm 12
2 x 4 mm 16
7/56
