Fenix TS2000 Series Operation Manual page 32

ESC SP n
[Name] Set right-side character spacing
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <FF>H
[Range]
[Description] Sets the character spacing for the right side of the character to [n x 0.125 mm (n x
0.0049")].
[Notes] The right side character spacing for double-width mode is twice the normal value.
●
This command is effective only when sent at the beginning of a line.
●
[Default] n = <04>H
ESC DC2 GS BEL
[Name] Save current settings into non-volatile memory
[Format] ASCII
Hex
Decimal
[Description] Saves current configuration into flash memory so when the printer is restarted, current
configuration will be loaded.
[Notes] The parameters that will be saved are line spacing, character spacing, character table,
character width and height.
ESC DC3 GS BS
[Name] Save default settings into non-volatile memory
[Format] ASCII
Hex
Decimal
[Description] Saves default configuration (factory settings) into flash memory so when the printer is
restarted, default configuration will be loaded.
[Notes] The parameters that will be saved are line spacing, character spacing, character table,
character width and height.
ESC ! n
[Name] Select print mode(s)
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <FF>H
[Range]
[Description] Selects print mode(s) using n as follows:
Bit
0
1
2
3
4
5
6
7
ESC SP
1B 20
27 32
ESC DC2
1B 12
27 18
ESC DC3
1B 13
27 19
ESC !
1B 21
27 33
OFF/ON Hex
OFF 00 Character font A (12 x 24).
ON 01 Character font B (8 x 16).
-- -- Undefined.
-- -- Undefined.
OFF 00 Emphasized mode not selected.
ON 08 Emphasized mode selected.
OFF 00 Double-height mode not selected.
ON 10 Double-height mode selected.
OFF 00 Double-width mode not selected.
ON 20 Double-width mode selected.
-- -- Undefined.
OFF 00 Underline mode not selected.
ON 80 Underline mode selected.
TS2000 PRINTERS OPERATION MANUAL
n
n
n
GS BEL
1D 07
29 07
GS BS
1D 08
29 08
n
n
n
Function
32/58
