Warning: You must wait at least 5 minutes after you restart the TX3 Nano
9.
3.13

Inputs and Outputs

The default configurations for the 2 inputs are described below.
3.13.1 Input 1
By default, Input 1 is configured as a Door contact. Input 1 connects to the door
sense switch. When this input is active it means the door is open and when this
input is inactive it means the door is closed.
When access is granted, activation of the door sense switch locks the main door
and resets the Unlock door timer. This function is typically used to prevent
'tailgating'. Input 1 also, when configured with a correlation, activates a general
purpose output to perform any required function.
In addition, this input:
•
•
•
TX3 Nano Configuration Manual
Copyright 2019
before proceeding.
After 5 minutes, sign into the Configurator, click Nano Settings, and
then click Restart Nano again.
The TX3 Nano restarts a second time and you are signed out of the
Configurator.
The TX3 Nano software is now updated.
senses if the door ever opened after it was unlocked as a result of access
being granted. If the door did not open even though the door was unlocked
for the programmed time duration, it is reported to the Configurator if the
Report door not open option is enabled (see section 3.14 on page
32).
senses a forced entry. If the door is locked and the door contact input
becomes active, the forced entry alarm activates. This can be changed by
selecting Disable forced entry alarm (see section 3.14 on page
32).
senses if the door is held open. This happens when the door is unlocked
and the door contact becomes active but does not get deactivated before
the Unlock door timer expires. At this time the door held open
warning timer starts. If the door is still open when this timer expires, a
Door held open trouble is reported to the Configurator.
When the door held open warning timer expires, the door held open alarm
timer starts. When the door held open alarm timer expires, a Door held
open alarm is reported to the Configurator.
TX3 Nano Settings
29
