4.
Edit a correlation
1.
2.
3.
Delete a correlation
•
Copy a correlation
•
3.16

Configure other TX3 Nanos

After you have configured one TX3 Nano, you can find other TX3 Nanos on the
network and configure them.
The list of discovered TX3 Nanos in the upper left corner of the Nano Settings
window shows all the TX3 Nanos on the network that you can configure. The
selected (darker) TX3 Nano is the TX3 Nano that you are currently configuring.
TX3 Nano Configuration Manual
36
Copyright 2019
For. Select the duration of the action up to a maximum of 600 minutes.
The default is 0 seconds.
Active. Select No to turn the correlation off, or select Yes to turn it on.
The default is Yes.
During schedule. If Always is selected, then the correlation is always
active. If a schedule is selected, then the correlation is active when the
selected schedule is active. See section 5 on page 49.
Click Save Changes at the top of the window.
Select the correlation on the left.
Provide the information as you would when creating a correlation.
Click Save Changes at the top of the window.
Click the trash icon beside the correlation.
Click the copy icon beside the correlation.

Figure 18. TX3 Nano Network

Selected TX3 Nano (the TX3
Nano that you are currently
configuring)
Other discovered
TX3 Nanos
