3.1

Overview

1.
Nano Settings
3.2

TX3 Nano Network

The list of TX3 Nanos in the upper left corner of the Nano Settings window
shows all the discovered TX3 Nanos on the network. The selected (darker) TX3
Nano is the TX3 Nano that you are currently configuring. See section 3.16 on
page 36 for information on configuring other TX3 Nanos.
Note:
TX3 Nano Configuration Manual
22
Copyright 2019
Click Nano Setting in the left pane.
The Nano Settings window appears.
Nano Settings
tab
Residents
Schedules
Elevator
Events
List of discovered
TX3 Nanos
Left Pane

Figure 10. Nano Settings

Before changing any settings, make sure to select the right TX3
Nano. The TX3 Nano that you have signed into is not always
selected by default in this list.

Figure 11. TX3 Nano Network

Inputs and Access
Outputs tab point tab
Selected TX3 Nano (the TX3
Nano that you are currently
configuring)
Other discovered
TX3 Nanos
TX3 Nano Settings
Correlations tab
Sync, Discover,
Global Settings
and Sign out
