Enable Elevator Restriction - Mircom TX3 Series Configuration Manual

6.
4.4

Enable Elevator Restriction

If the job contains Elevator Restriction Units, then you must copy the elevator
restriction information for each resident from the TX3 Configuration and
Monitoring Utility to the TX3 Nano Configurator. Follow the instructions below
to do this.
Note:
Enable Elevator Restriction
1.
2.
TX3 Nano Configuration Manual
44
Copyright 2019
NSL Relay Code. If you selected NSL, enter the NSL unit relay code
associated with the resident.
Ring Pattern. If you selected NSL, select the resident's phone ring pattern
from the list.
Maximum # of Rings. If you selected NSL, specify the numbers of rings
of each call before the TX3 Nano reports no answer and disconnects the
call. For ADC lines, this setting is not used and the number of rings is
determined by the central office.
Priority. Click the up arrow or down arrow on the left to move the number
up or down in the priority. This indicates which number the TX3 Nano
dials first. Each resident can have up to 3 numbers. If the call fails or is
busy, the TX3 Nano dials the next number in the list.
Label. In the menu to the right of the Type menu, select Home, Mobile,
Work, or Other.
Click Save Changes at the top of the window.
Elevator restriction is configured in the TX3 Configuration and
Monitoring Utility software. See LT-995 TX3 System
Configuration and Administration Manual on www.mircom.com
for instructions on setting up elevator restriction.
Follow the instructions in section 6 on page 54 to add the elevator
restriction units and floor groups to the TX3 Nano, if you have not already
done so.
On the Resident page, click the Advanced tab.
Residents
