Multitron - Operating Manual
Accessories
Tray with flat clamping assembly (horizontal incubation):
The flat clamping assembly is a profile made of sheet metal that is
equipped with an angled strip (2). On the other side, there is an edge
featuring a foam rubber strip (3). There are two spacers on the edge
(1) for positioning microtitre plates or deep-well plates.
2
1
3
Tray with clamping assemblies tilted at an angle of 20° (angled incu-
bation):
The tilted clamping assembly is a wedge-shaped metal sheet with
two profiles. The lower profile is an angled bar (3). The upper profile
is a U profile into which the cellular rubber string (2) is inserted. There
are two spacers on the upper edge (1) for positioning the microtitre
plates or deep-well plates.
1
3
2
The trays with clamping assemblies are designed for microtitre and
deep-well plates with dimensions 85.1 mm x 127 mm. To ensure suf-
ficient clamping force can be achieved, plates with a web height of at
least 3 mm must be used.
20 August 2020
Page 61 of 158
