Adjustable throw
If the device features an adjustable throw, there are four possible po-
sitions for the eccentric throw:
12.5 mm

19 mm

25 mm

50 mm

The counterweights are also adjustable to reduce vibrations during
operation.
INFORMATION
The throw may only be adjusted by personnel that has received
appropriate training and authorisations. If in doubt, contact IN-
FORS HT (see contact details on page 2).
Operation
Rotation speed
The parameter is operated via the operating panel.
Beside the actual value, the symbol
the display.
For an exact description of how to set the parameters, see chapter
7.4 "Adjusting, Activating and Deactivating Parameters", page 90.
INFORMATION
The permissible load weights depend on the position of the device
in the stack, the throw and the shaking speed (see chapter 7.2.4
"Tips & Tricks for Loading the Tray", page 82).
Technical data and setpoints
For a detailed description of the technical data and possible maxi-
mum rotation speeds, see chapter 12.4.1 "Rotation Speed Parameter
(Shaker Drive)", page 144.
Multitron - Operating Manual
Setup and Function
RPM min
and the unit -1 appear on
