7.7 Settings Menu (Option Function)

Procedure
7.7.1

Setting the Upper Limit for the Rotation Speed

20 August 2020
The settings menu enables you to adjust the main device settings. To
open the device's settings menu, proceed as follows:
1. Tap the OPTION key for at least 2 seconds.
On the top display, the
Setpoint High.
and
make the desired settings.
Tapping the OPTION key again lets you switch to the next func-
tion. If no key is tapped for 60 seconds, the display returns to
normal operating mode. If all functions are clicked through, the
device also returns to normal operating mode.
INFORMATION
The limits for the allowed setpoints of the parameters can only be
set within a few factory-set values.
If the setpoint for a parameter is limited in the settings menu of
the device and an attempt is made to enter a higher value, the
bLoc
message appears.
The following chapters explain the individual functions.
Top display: OPt , Setpoint
RPM
Bottom display:
The maximum rotation speed that can be entered as a setpoint can
be restricted. To do so, tap the SET key (the sign
and then use the Plus or Minus key to set the desired value.
Multitron - Operating Manual
OPt
message appears with the symbols
The Settings menu is thus open and you can
and High
Operation
Setpoint
appears)
