12.5.4 Pressure Elimination Unit for Direct Steam Humidification

20 August 2020
Technical Data and Specifications
Specifications for the connection / water quality
Description
Connection (hose Ø)
Input pressure
Water hardness
Water conductivity
Dissolved solids
ATTENTION
Using tap water can quickly lead to limescale in the vaporiser of
the humidification unit, which would affect correct functioning.
Ultra pure water (WFI, water for injection purposes) must not be
used either as this is highly corrosive and thus damages the device.
Adding detergents, disinfectants or similar chemicals to the water
for the direct steam humidification can damage the device. Only
use water without additions, in accordance to the specification.
Specifications for the humidity sensor
Description
Sensor type
Measurement range
Response time
Temperature range for use
Dimensions
Description
Depth
Height
INFORMATION
For detailed information on the external dimensions, refer to the
dimension drawings (see chapter 4.3.4 "Dimensions", page 47).
Multitron - Operating Manual
Value Unit
6 to 7 mm
0 to 0.3 bar
< 0.01, CaCO
mmol/L
3
equivalent
min. 5 / max. 20 μS/cm
< 10 mg/L
Value Unit
EE071 HCT01-00D
20 to 90 %
< 300 ms
- 40 to 80 °C
Value Unit
185 mm
337 mm
