Infors HT Multitron Operating Manual page 102

Multitron - Operating Manual
Operation
Page 100 of 158
4. Tap the ON/OFF key in the upper setting key area to activate
Time 1
the timer ( ).
On the upper alphanumeric display the message
a very short time and then the time entered is shown
In the separate timer display area the sign
Phase 1
sign lights up for the first time.
INFORMATION
It is not possible to set the parameters for the first phase as long as
the timer for the first phase has not been activated.
Entering the setpoints for the first phase and switching on the
parameters
As soon as the timer for the first phase (
on, the different parameters for phase 1 can be selected using the
Select key and afterwards be switched on.
5. Tap the Select key to select the desired parameters.
In both display areas the first integral pair of parameters (
RPM
and ) appears with the last setpoint values entered or the
OFF
message .
Setpoint
The sign indicates, that the setpoints can be entered.
INFORMATION
In this phase of the programming process the sign
mains lit up and does not disappear after 10 seconds.
6. Tap the Plus or Minus key in the corresponding setting key area
to set the desired setpoint values and switch the parameters on
using the ON/OFF key.
INFORMATION
With the Select key the parameters and the time entered for the
first phase can be selected and changed over and over again.
on appears for
Timer
is lit up and the
Time 1
) has been switched
Temp
Setpoint
re-
20 August 2020
