To inhibit operation of a cross-point button
Hold down the button which "Inhibit Set" is assigned, and press the cross-point
button whose operation you want to inhibit.
The button you pressed flashes amber, and this makes the operation inhibited.
Notes
Even when you inhibit operation of a cross-point button, macro attachment
settings are still possible (see "Setting and Canceling a Macro Attachment" in
Chapter 16 (Volume 2)).
To clear a cross-point button operation inhibit setting
Hold down the button to which "Inhibit Set" is assigned, and press the button
whose operation is inhibited (flashing amber).
This clears the operation inhibit setting for the button you pressed.
To clear all operation inhibit settings
Press the button to which "Inhibit Set" is assigned and the button to which
"Inhibit All Clear" is assigned simultaneously.
Selection of signals linked with the audio mixer
When you select a signal in a switcher bank background A, key 1 or key 2 row
(of the CCP-6224/6324 control panel in AUX control mode) or AUX bus
control block (of the CCP-8000), and the bank and signal are set to be linked
to the audio mixer, then the program output of the audio mixer follows the
signal selection.
For details of the setting, see "Cross-Point Settings (Xpt Assign menu)" in
Chapter 19 (Volume 3).
Notes
• For details of audio mixers that can be connected, contact your Sony service
or sales representative.
• When the signal is switched with a snapshot, keyframe, and so on, the audio
mixer is not linked.
• When bus fixed mode is selected in setup (see page 172), the audio mixer
program output is linked to the bus output as the background.

Signal Name Display

You can attach a name (source name) to each signal assigned to a cross-point
button, with a maximum of 16 characters.
