RGB Clip Operations

For each of the R, G, and B signals, you can make dark clip and white clip
adjustments.
Making RGB clip adjustments
1
In the CCR menu, press VF1 'CCR1' and HF4 'RGB Clip.'
The RGB Clip menu appears.
2
In the <RGB Clip> group, press [RGB Clip], turning it on.
3
In the <RGB Clip Adjust> group, select the item you want to adjust.
Dark: dark clip adjustment
White: white clip adjustment
4
Adjust the following parameters.
Knob
1
2
3
4
a) When Dark is selected
b) When White is selected
To return the parameters to their default settings
In the <RGB Clip> group, press [Unity].

Luminance Processing Operations

After converting a signal to which RGB color correction has been applied to a
YUV signal, divide the luminance levels into three regions, referred to as Dark,
Middle, and Bright, and apply video signal adjustments to these regions.
Parameter Adjustment
Red Red signal adjustment
Green Green signal adjustment
Blue Blue signal adjustment
All Simultaneous RGB adjustment
Setting values
a)
–50.00 to +149.99
b)
–49.99 to +150.00
a)
–50.00 to +149.99
b)
–49.99 to +150.00
a)
–50.00 to +149.99
b)
–49.99 to +150.00
Red value is shown
Color Corrector Functions
461
