3D Support
When On, different signals are used for left
and right.
When there is no indication (Off), the same
signal is shared between left and right.
Link number
Using any of the following methods, select the link number to operate on.
• Press directly on the list.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knobs.
Knob Parameter
1 Link No
3 Num
Press [3D Input Link], and set the link to either of the following.
• To use separate left and right signals, set to On.
• To use the same signal shared between left and right, set to Off (no
indication).
Notes
When this is set to "Off," one signal of the predetermined pair cannot be
used.
For example, for IN1 and IN18, IN18 cannot be used, and is grayed out in
the list.
Repeat steps 3 and 4, to set all of the primary inputs in 3D mode.
Setting
Link number
Select the number of consecutive
numbers from the selected link number
When On, left and
right are reversed.
Values
1 to 80
1 to 80
