Recalling A Continuous Sequence Of Still Images (Animation) - Sony CCP-8000 Series User Manual

5
Press [Record Enable], turning it on.
The signals of frame memory source buses 1 and 2 are assigned to the pair
of FMs selected in step 2, the recording function is now possible.
6
Input the file name if required.
Pressing [File Name] displays the keyboard window and you can enter the
first character string (up to four characters) of the file name.
7
Set the recording time if required.
Pressing [Duration] displays the numeric keypad window, in which you
can enter the recording time in the form of timecode.
If you set the recording time to zero, this uses all frame memory in which
storing is possible for recording.
8
If required, set video processing for the selected signal.
For details of the operating procedures, see "Setting video processing"
(page 377).
9
Press [Record], to start recording.
When the recording time is set, recording stops once the time has elapsed.
10
Press [Stop] to stop recording.
Even if the recording time is set, you can still stop recording before the set
time has elapsed.
Recalling a Continuous Sequence of Still Images
(Animation)
You can use a continuous sequence of images captured with the record function
as keyframes to create an effect. By executing this effect you can recall the
continuous sequence (animation).
Notes
• For example, to create an effect using FM1, FM1 must be assigned to a user
region.
• To execute the effect, you must assign the user region to which FM1 is
assigned to a region selection button in the numeric keypad control block and
the Multifunction Flexi Pad control block. (For details of assigning to region
389
Still Image Operations
