Powerful frame memory functions
In an MVS-8000 system, an HDTV system can hold 58 still image frames (88
frames in 720P/59.94 format), and an SDTV system can store 222 frames in
memory, while up to eight frames can be recalled and used simultaneously.
In an MVS-8000A system and MVS-8000G system, an HDTV system can
hold approximately 1,000 still image frames or 2,000 frames in 720P/59.94
format, and an SDTV system can hold approximately 5,000 frames in 480i/
59.94 format or 4,000 frames in 576i/50 format in memory, and up to eight
frames can be recalled and used simultaneously.
Link operation with DME
By means of the dedicated DME interface, a range of DME functions including
DME wipes and processed keys can be handled as switcher functions.
By connecting two MVE-8000/8000A or MVE-9000 units, in any
combination, you can interface to a maximum of eight DME channels.
Designed for use in a live broadcasting environment
Flexible control panel layout
Because of its modular design, the various sections of the control panel can be
laid out as required. This allows a flexible layout appropriate to the system
operation.
High-performance user interface
The menu control block provides a large color LCD panel, with rapid touch-
panel menu selection.
The source name displays and buttons in the Flexi Pad and shotbox control
TM
blocks have color backlit LCD displays. The signal names, and graphical
representations of the patterns associated with buttons provide intuitive
feedback, and allow the immediate decisions that are required in a live
operating environment.
