Sony CCP-8000 Series User Manual page 504

Using pairs of primary input numbers reversed right-to-left
Press [L/R Input Exchange], setting it to On, to swap the left and right signals,
and reverse the indications in the list.
For example, when the left signal is IN1, and the right signal is IN18, this
assigns IN18 to the left signal and IN1 to the right signal.
Notes
When [3D Input Link] is off and [L/R Input Exchange] is set to On, then the
other input of the pair can be used.
For example, when using IN1 shared between left and right, you can also use
IN18 shared between left and right, and IN18 also appears in the list.
To assign inputs with the primary input numbers reversed left-to-
right to cross-points
1
In the Input Link menu, set [L/R Input Exchange] to On, then display the
Engineering Setup >Panel >Xpt Assign >Main, V/K Pair Assign menu.
In the Source field, "3D Exchange=xx" appears ("xx" is the input number
linked to the input number at the position of the cursor).
In the example of the following figure, for IN36 "3D Exchange=53"
appears.
2
Press [Set].
This sets IN53 in place of IN36.
Left-right reversed
number is assigned
Output connector numbers for the left and right signals
The combinations of connector numbers for left and right signal outputs are
also fixed.
For details of the input and output signals in 3D mode, consult your Sony
representative.
"xx" is the input number
linked to the input number at
the position of the cursor
3D Support
503
