Tested Cables - Brainlab CURVE DUAL DISPLAY Technical User Manual

Compliances
5.4.5

Tested Cables

Use of Specified Cables
The use of accessories and cables other than those specified (with the exception of cables
sold by Brainlab as replacement parts), may result in increased emissions or decreased
immunity of the equipment.
For a navigation station the following shall apply: S-Video type cables provided by the user
shall be equipped with a ferrite on both ends (e.g., Würth Electronic Art. No. 742 711 31 or
equivalent). USB type cables provided by the user shall be equipped with a ferrite on both
ends (e.g., Würth Electronic Art. No. 742 712 22 or equivalent).
Cable Specifications
Curve system cables that have been tested for emission and immunity conformity:
Cable
Camera
Power
Potential equalization cable
Composite In
Serial port
Hospital Network ("Intraoper-
ative Data")
USB (I-O-shield)
Display 1 and 2 In
SDI In
Microscope
64
Specification
Provided by Brainlab; 10 m long
Provided by Brainlab; 5 m long
Provided by Brainlab; 5 m long
Coax cable (min. 0.5/3.7 diameter), shielded, terminated, 75
Ohm; max. 5 m long
RS232 cable, shielded, terminated, 4.7 kOhm
CAT6 SFTP cable, shielded, not terminated, provided by Brain-
lab; 5 m long
USB 2.0 cable, shielded, not terminated
Category 2 HDMI, Type A plug connector; max. 5 m long
Coax cable (min. 0.5/3.7 diameter), shielded, terminated, 75
Ohm; max. 5 m long
Provided by Brainlab; 10 m long
Technical User Guide Rev. 1.2 Curve Dual Display, Curve Single Display Ver. 1.0
