Recurrent Test Requirements
4.2.2

Testing Overview

Measuring Devices
The measurement instructions provided are an example for one measuring device.
The individual steps may vary from one measuring device to another. Refer to the corresponding
manufacturer's instructions for the measuring device you are using.
NOTE: If you are unsure that your measuring device is suitable, contact Brainlab support.
Required Test Steps
Steps
1.
2.
3.
4.
5.
6.
NOTE: For details on the tests to be performed, see page 43.
Test Guidelines
When performing recurrent tests:
• Perform required test steps in the order defined above.
• Measure all areas of the system indicated in the following chapters.
• All tests must be passed before the device can be considered safe.
• The calibration of the measuring device must be valid at the time of measurement.
• Perform all tests according to IEC 62353.
NOTE: The measurement outlet connection of the measuring device must remain established
during the entire measurement cycle. If you unplug the measurement outlet during measurement,
the measuring device recognizes that the connection is no longer established and you will need to
repeat the entire test.
If a test does not pass, device must be repaired by Brainlab support. After repair, repeat the
entire electrical safety test from the beginning.
Safety Inspection Form
• Print out or make a copy of the safety inspection form (from page 43).
• Enter the inspection results.
• Compare measured values with critical values (defined on page 43) to determine if the test
has been passed.
• Keep form as a record of the inspection.
42
Perform visual inspection.
Check protective earth resistance.
Check equipment leakage current.
Perform functional test.
Report and evaluate results.
Check and prepare system for normal use.
