UPS
2.4.3

UPS Battery

Check Battery
Inspect the battery regularly (see page 71).
Battery Disposal
Battery replacement cartridges facilitate environmentally friendly recycling of batteries and should
meet all national regulations for battery disposal.
Do not attempt to remove or exchange batteries from the UPS. Batteries can only be
exchanged by Brainlab or authorized partners.
Do not remove the Monitor Cart cover.
Empty batteries must be properly disposed of or recycled according to your organization
rules and local legislation. For battery disposal and replacement, arrange an appointment
with Brainlab support.
How to Charge the UPS
To optimize the lifetime of the UPS, it should be completely discharged and recharged once every
three months (see page 72).
Turn system on again and repeat this process until the system shuts down automatically, emitting
a long beep followed by short beeps. The battery is now empty.
Steps
1.
2.
3.
NOTE: It is possible to use the Monitor Cart while the UPS is charging, however if mains power is
lost, standby power will last less than five minutes.
Battery Specifications
Specification
Recharge time
Run time
Battery life
Battery type
30
Discharge the battery by unplugging mains power from the wall outlet while the system is
running.
Wait until the system shuts down (max. five minutes).
Turn system on again and repeat step 1 until the system shuts down automatically, emit-
ting a long beep followed by short beeps.
The battery is now empty.
To recharge, plug in the system and turn on the mains power.
Allow the system to charge for two hours.
Description
Two hours (full recovery)
Max. five minutes
Arrange for Brainlab support to replace the UPS battery every three years
(if inspected regularly).
The UPS is composed of two 12V, 12 Ah valve-regulated, spill-proof, main-
tenance-free, lead-acid batteries.
