ELECTRICAL SAFETY
Point Tested
Left screw on center joint of
articulated arm
Screw on left side of Moni-
tor Cart transport handle
Composite In plug at con-
nection panel
On/off button
Screw on camera rotation
hinge
Camera pitch hinge
Technical User Guide Rev. 1.2 Curve Dual Display, Curve Single Display Ver. 1.0
Measured Value
Test
Passed?
47
