SYSTEM OVERVIEW
2.3
Camera Cart
2.3.1
Overview
Components
No.
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
Technical User Guide Rev. 1.2 Curve Dual Display, Curve Single Display Ver. 1.0
①
⑪
⑩
⑨
Component
Camera Cart - Curve Single Display
Camera Cart - Curve Dual Display
Motorized joint (②only)
Motor control unit (②only)
Height adjustment handle (② only)
Telescopic post (② only)
Camera control unit (② only)
Camera Cart base
Transportation handle with cable hooks
Camera handle
Camera
②
⑧
Figure 6
③
④
⑤
⑥
⑦
