TROUBLESHOOTING
3.3.3

Failure Indication Screens

Notification Messages
Message
Scanning for Signal!
Switching to Signal on Display
1 In.
Error: Wrong or No Signal!
Change source on Display In or
contact Brainlab Support
Switching to internal signal.
No motorized camera available.
Motors are switched off at cam-
era cart.
It is safe to switch off system
Technical User Guide Rev. 1.2 Curve Dual Display, Curve Single Display Ver. 1.0
Explanation
System is checking available signals. Information disappears
after a few seconds and either the image is displayed or anoth-
er error message appears.
A signal has been attached to the Display 1 In port on the Con-
nection Panel of the Monitor Cart. The system is setting up
the display so that the signal can be displayed.
This message may also say Display 2 In (with Curve Dual Dis-
play system). The message is always displayed on the corre-
sponding screen.
If an external source has been attached to Display 1 In (or Dis-
play 2 In with the Curve Dual Display), the type of signal is
not recognized and cannot be displayed. Please remove the
source from the port.
If there is no external signal attached, please contact Brainlab
support.
An external source has been removed and the system is
switching back to the Brainlab software.
When pressing the motor control buttons on the Curve Single
Display system this message is displayed as the Curve Sin-
gle Display does not offer motorized camera movement. On
the Curve Single Display, these buttons do not have a func-
tion.
Motorized camera movement on the Curve Dual Display is
not working because the switch on the back of the Camera
Cart base is turned off.
The system has been shut down and it is safe to switch off the
mains power switch.
