COMPLIANCES AND SPECIFICATIONS
5.3

System Specifications

5.3.1

Physical Characteristics

Monitor(s)
Height
Width
Depth
Weight
Monitor Angle Flexi-
bility
NOTE: These values are based on one monitor only, without the protection cover.
Camera
Height
Width
Depth
Weight
NOTE: These values are based on the camera without the protection cover.
Camera Carts
Weight
Footprint
Max. Height
Monitor Carts
Weight
Footprint
Height
Technical User Guide Rev. 1.2 Curve Dual Display, Curve Single Display Ver. 1.0
405 mm
615 mm
75 mm
8 kg
See System User Guide.
76 mm
585 mm
115 mm
3 kg
Camera Cart - Curve Single
Display
77.5 kg
726 x 725 mm
2194 mm
Monitor Cart - Curve Single
Display
76 kg
757 x 757 mm
1499 mm
Camera Cart - Curve Dual Display
87.5 kg
726 x 725 mm
2530 mm
Monitor Cart - Curve Dual Display
92 kg
757 x 757 mm
1499 mm
