SYSTEM OVERVIEW
Components - Curve Dual Display
No.
①
②
③
④
⑤
Technical User Guide Rev. 1.2 Curve Dual Display, Curve Single Display Ver. 1.0
①
Component
Camera Cart - Curve Dual Display (with telescopic post and motorized controls)
Camera
Monitors
Touchscreen
Monitor Cart - Curve Dual Display, including medical computer unit
②
③
Figure 2
④
⑤
