Performing Tests

4.3.2

Equipment Leakage Current

General Information

Connect the measurement tip of your measuring device with the conductive parts shown in the

table starting from page 46 and measure the leakage current.

Equipment Leakage Current Measurement Points

Point Tested

Display fixation screw

Second display fixation

screw ( Curve Dual Display

only)

Left screw on inner articulat-

ed joint

Left screw on inner articulat-

ed joint of second arm

( Curve Dual Display only)

Technical User Guide Rev. 1.2 Curve Dual Display, Curve Single Display Ver. 1.0

Measured Value

Test

Passed?
