Setting The Rs485 Address - MICRO-EPSILON capaNCDT 6110 IP Operating Instructions Manual

RS485 Interface
5.2.4
The RS485 address of controller can be changed with this telegram:
Master:
SD
0x68
DA
SA
FCS
New_addr
Answer Slave (short acknowledgement), on success:
SC
0xE5
No response:
No response indicates that an error has occurred in the address alignment. The controller still has the old
address.
The new address is valid only after a reboot of the controller.
capaNCDT 61xx/IP

Setting the RS485 Address

LE LE SD DA
0x09 rep rep x
Destination Address (= old Slave address)
Source Address = Master Address (e.g. 0x01)
Checksum (sum of all bytes without SD, LE, LErep, SDrep, FCS, ED; without overflow, only
8 bits)
New address (in range 1...126)
SA FC DSAP SSAP
x 0x43 0x37 0x3E
new_addr ID_Hi ID_Lo Lock
x 0x0 0x0 0x0
FCS ED
x 0x16
