Installation and Assembly
4.3.4
Type
CCgx,xE
Fig. 18 Dimensional drawing sensor cable CCgxE
Dimensions in mm (inches)
capaNCDT 61xx/IP
Cable with Type E Connector
Model
With patented min-
iature plug for flat
sensors
24 (.94)
Cable length
Bending radius
static >10 mm
4 m
dynamic >22 mm
(recommended 30 mm)
36.5
(1.44)
+1.0
Cable length x
Sensor cable suitable
for sensors
CSF2,
CSF4,
CSF6
10.0
(.39)
Seite 26
