RS485 Interface
Data[0]
Data[1]
Data[2]
Data[3]
Data[4]
Data[5]
Data[6]
Data[7]
Data[8]
Data[9]
Data[10] 0x32
Data[11] 0x00
Data[12] 0xB9
Data[13] 0x44
Data[14] 0x32
Data[15] 0x00
A total of 3 measurement values (= m) were added since the last measuring value request in controller and
transferred thereby.
capaNCDT 61xx/IP
Value Name
0x22 Counter [7:0]
0x01 Counter [15:8]
0x03 Packet length m [7:0]
0x00 Filler byte [7:0]
0xB1 Measuring value 1 [7:0]
0x44 Measuring value 1 [15:8]
0x32 Measuring value 1 [23:16]
0x00 Measuring value 1 [31:24]
0xAC Measuring value 2 [7:0]
0x44 Measuring value 2 [15:8]
Measuring value 2 [23:16]
Measuring value 2 [31:24]
Measuring value 3 [7:0]
Measuring value 3 [15:8]
Measuring value 3 [23:16]
Measuring value 3 [31:24]
Explanation
Measuring value counter = 0x0122
= 290
m = 3 -> 3 meas. values
filler, can be ignored
meas. value = 0x003244B1
(0xF00000 = 100 %)
-> 0x003244B1 = 20.945 %
e.g. 200 µm sensor -> 41.89 µm
Next measurement value, see above
Next measurement value, see above
