capaNCDT 61xx/IP
Tension at the cable is inadmissible!
Mounting with Thread, Series CSEx/Mx Sensors
Active measuring surface sensor,
This sensor mounting option offers maximum reliability be-
cause the sensor is clamped around its cylindrical housing. It
is absolutely necessary in difficult installation environments,
for example on machines, production plants et cetera.
Fig. 8 Circumferential clamping with clamping ring
For holders with an internal thread, a mounting nut is suffi-
cient for attaching the sensor. For thin holders, Micro-Epsilon
recommends mounting nuts on both sides for mounting.
Attach the sensor preferably at the end of the thread towards
the active measuring surface. Please note the maximum
torque, see
Fig.
10.
Fig. 9 Mounting with thread
connector side
